Challenger 601-3R

N895CC  Serial Number 5177

WATCH VIDEO

Airframe
Total Time 8738.5 Hours
Total Landings 4498

Engines
General Electric CF34-3A1 – GE OnPoint Program
Left Engine - S/N 807265
8682.3 Hours Total Time, 4453 Total Cycles

Right Engine - S/N 807250
8648.7 Hours Total Time, 4455 Total Cycles

Auxiliary Power Unit
Honeywell GTCP 36-150 – MSP Gold Program
S/N P-466C
4970.5 Hours Total Time

Avionics
Collins Pro Line II
Dual Honeywell EDZ-815 5-tube EFIS
Dual Collins VHF-22B Comms with 8.33 Spacing
Dual Collins VIR-32 Navs with FM Immunity
Dual Collins ADF-462 ADFs
Dual Collins DME-42 DMEs
Dual Collins HF-9000 HFs with SELCAL
Dual Honeywell ADZ-810 Air Data Computers
Dual Honeywell NZ-2000 FMS with Weather Graphics
Dual Honeywell Laseref III IRS
Dual Honeywell HG-2021 12-Channel GPS System
AlliedSignal AFIS
Honeywell RT-300 Radar Altimeter
Dual Collins TDR-94D Mode S Transponders
Honeywell TCAS-II with Change 7
Honeywell Primus WX-880 Weather Radar
Honeywell LSZ-860 Lightning Sensor System
XM Weather

Avionics (Cont'd)
Honeywell Mark V EGPWS
Honeywell SPZ-8000 Autopilot System
Aircell ST 3100 Satcom System with Cordless Handset
Aircell ATG 4000 Gogo System with Wi-Fi
Artex 406 MHz ELT with Nav Interface
Fairchild GA100A Cockpit Voice Recorder
Fairchild F1000 Flight Data Recorder

Additional Features
GE OnPoint Engine Program ($187 per engine/hr)
APU MSP Gold Program ($42 per APU hr)
Smart Parts Program ($618 per hr)
Aircell ATG 4000 Gogo System with Wi-Fi
Flight Deck Jumpseat
Forward “S” Style Galley
Large Convection Oven and Microwave
Airshow 400 with Cockpit Controller
Two 14” LCD Bulkhead Monitors
Three 8.4” Plug-in LCD Monitors
Fax/Copier/Printer with Print Server and Hub
Dual Audio International DVD Players
10-Disc CD Player/Changer
Audio Passenger Briefing System
Dual EROS Crew Oxygen Masks
K-C Aviation External Nose Door Release System
Remote Re-Fuel Panel in Cockpit
Additional Cabin Windows Installation

Other
No Known Damage History
FAR Part 135 Compliant
MSG-3 Maintenance Program
240 Month & Gear Restoration 02/15 at Standard Aero
CAMP Maintenance Program

Interior
Ten-passenger fireblocked interior configured with a forward four-place club seating group featuring comfortable, oversized, berthable seats, and an aft four-place divan opposite two comfortable, oversized club seats. All individual passenger seats are completed in Taupe leather with the divan completed in a Tan fabric. Headliner, PSU and cabin sidewalls are completed in ultraleather, and complemented with a Taupe berber carpet. Woodwork is Walnut veneer completed in a hi-gloss finish.

Cabin entertainment system includes a 10 disc CD changer and dual DVD players providing video on two 14” monitors located on the front and aft cabin bulkheads. Additional video receptacles allow the use of three individual 8.4” LCD monitors located at passenger seating areas. An Airshow 400 system provides passengers with worldwide aircraft position and information data.

A forward “S” galley includes a large convection oven, microwave, dual coffee makers, water system, glassware storage, china storage, sink, 32 can soda storage dispenser, large cold storage, and multiple storage drawers for snacks, beverages, ice, and trash. Additional storage opposite the galley includes a wine rack and coat closet.

Exterior
Overall Matterhorn White with Sedona Red and Black accent stripes. New paint completed by Duncan Aviation, April 2011.
